2009 Volkswagen Transporter Base Pricing and Spec
From
$45,990
excl. on-roads
Overview
The 2009 Volkswagen Transporter Base is a four-wheel drive, 4-door Panel Van that was released to the Australian market on 4th August 2008 classified as a T5. The Volkswagen Transporter is regarded as a Van under 3.5t built in Germany and when it was new had prices starting at $45,990.
This Volkswagen Transporter is powered by a 2.5L 5-cylinder engine that has 128 kW of power (at 3500 rpm) and 400 Nm of torque (at 2000 rpm) via a Six-speed Manual transmission. Volkswagen claims the Transporter Base uses 9.7L/100km of Diesel in the combined city and highway cycle while putting out 262g of CO2. It has a 80L fuel tank, meaning it should be able to travel 825km per full tank
The Volkswagen Transporter measures 1969mm (77.5 inches) in height, 5290mm (208.3 inches) in length, 1904mm (75.0 inches) in width with a 3400mm (133.9 inches) wheelbase that brings about a total of 1905kg (4199.8 lbs) of unladen weight. The Transporter Base comes standard with 215/65 R16 106 ? front tyres and 215/65 R16 106 ? rear tyres. It has a 36 month, 100,000 km warranty.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | TURBO PUMP INJECTION |
|---|---|
| Size (cc) | 2460 |
| Size (L) | 2.5L |
| Cylinders | 5 |
| Camshaft | Dual Overhead Cam |
| Valves/Ports per Cylinder | 10 |
| Power | 128kW |
| Power RPM | 3500 |
| Torque | 400Nm |
| Torque RPM | 2000 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 6 SP MANUAL |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | Strut |
| Suspension Rear | Trailing Arm |
| Steering Mechanism | - |
| Drive | 4x4 |
| Fuel Combined (L/100km) | 9.7 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 80 |
| Fuel Type | Diesel |
| e10 Compatible | - |
| CO2 Combined | 262 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC - VENTILATED |
| Tyre Front | 215/65 R16 106 ? |
| Tyre Rear | 215/65 R16 106 ? |
| Front Rim Size | 6.5x16 |
| Rear Rim Size | 6.5x16 |
| Vehicle Height (mm) | 1969 |
|---|---|
| Vehicle Length (mm) | 5290 |
| Vehicle Width (mm) | 1904 |
| Ground Clearance (mm) | - |
| Wheelbase (mm) | 3400 |
| Turning Circle (m) | 13200 |
| Unladen Weight (kg) | 1905 |
| Gross Combined Weight (kg) | 5200 |
| Gross Vehicle Weight (kg) | 3000 |
| Track Front (mm) | 1628 |
| Track Rear (mm) | 1628 |
| Towing Capacity Brake (kg) | 2000 |
| Towing Capacity Unbraked (kg) | 750 |
| Country Of Origin | Germany |
|---|---|
| Number of Doors | 4 |
| Seats | 2 |
| Service Interval KMs | 15000 |
| Service Interval Months | - |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 2009-06-21 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EU4 |
