Overview
The 2012 Nissan Navara DX is a four-wheel drive Single Cab Chassis that was released to the Australian market on 27th January 2011 classified as a D22. The Nissan Navara is regarded as a single cab chassis built in Thailand with prices from a dealer as a used car starting at $32,635.
The Nissan Navara is a four-wheel drive 2 door with 3 seats, powered by a 2.5L 4 engine that has 98 kW of power (at 3600 rpm) and 304 Nm of torque (at 2000 rpm) via a Five-speed Manual. Nissan claims the Navara DX uses 9.1L/100km of diesel in the combined city and highway cycle while putting out 241g of CO2. It has a 75L fuel tank, meaning it should be able to travel 824km per full tank.
The Nissan Navara measures 1700mm (66.9 inches) in height, 5020mm (197.6 inches) in length, 1825mm (71.9 inches) in width with a 2950mm (116.1 inches) wheelbase that brings about a total of 0kg (0.0 lbs) of unladen weight. The Navara DX comes standard with null front tyres and null rear tyres. It has a 36 month, 100,000kmkm warranty.
The 2012 Nissan Navara DX has a 220mm ground clearance with a 2800kg braked and 750kg unbraked towing capacity.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | TURBO DIESEL COMMON RAIL |
|---|---|
| Size (cc) | 2488 |
| Size (L) | 2.5L |
| Cylinders | 4 |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 98kW |
| Power RPM | 3600 |
| Torque | 304Nm |
| Torque RPM | 2000 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 5 SP MANUAL |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | wishbone |
| Suspension Rear | beam |
| Steering Mechanism | HYDRAULIC POWER STEERING |
| Drive | 4x4 |
| Fuel Combined (L/100km) | 9.1 |
|---|---|
| Fuel Urban (L/100km) | 10.4 |
| Fuel Extra Urban (L/100km) | 8.4 |
| Tank Size (L) | 75 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 241 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DRUM |
| Tyre Front | - |
| Tyre Rear | - |
| Front Rim Size | 6x16 |
| Rear Rim Size | 6x16 |
| Vehicle Height (mm) | 1700 |
|---|---|
| Vehicle Length (mm) | 5020 |
| Vehicle Width (mm) | 1825 |
| Ground Clearance (mm) | 220 |
| Wheelbase (mm) | 2950 |
| Turning Circle (m) | 12000 |
| Unladen Weight (kg) | 0 |
| Gross Combined Weight (kg) | 0 |
| Gross Vehicle Weight (kg) | 2860 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 2800 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | - |
|---|---|
| Country Of Origin | Thailand |
| Number of Doors | 2 |
| Seats | 3 |
| Service Interval KMs | 10000 |
| Service Interval Months | 0 |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 2012-10-31 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EU4 |
