Overview
The 2009 Mercedes-Benz Vito Base is a rear-wheel drive, 5-door Panel Van that was released to the Australian market on 3rd January 2009. The Mercedes-Benz Vito is regarded as a Van under 3.5t built in Spain and when it was new had prices starting at $54,990.
This Mercedes-Benz Vito is powered by a 3.0L 6-cylinder engine that has 150 kW of power (at 3800 rpm) and 440 Nm of torque (at 1600 rpm) via a Five-speed Automatic transmission. Mercedes-Benz claims the Vito Base uses 9.2L/100km of Diesel in the combined city and highway cycle while putting out 244g of CO2. It has a 75L fuel tank, meaning it should be able to travel 815km per full tank
The Mercedes-Benz Vito measures 1900mm (74.8 inches) in height, 5223mm (205.6 inches) in length, 1901mm (74.8 inches) in width with a 3430mm (135.0 inches) wheelbase that brings about a total of 1920kg (4232.9 lbs) of unladen weight. The Vito Base comes standard with 225/55 R17 ? front tyres and 225/55 R17 ? rear tyres. It has a 36 month, unlimited km warranty.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | TURBO DIESEL COMMON RAIL |
|---|---|
| Size (cc) | 2987 |
| Size (L) | 3.0L |
| Cylinders | 6 |
| Camshaft | Dual Overhead Cam |
| Valves/Ports per Cylinder | 24 |
| Power | 150kW |
| Power RPM | 3800 |
| Torque | 440Nm |
| Torque RPM | 1600 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 5 SP AUTOMATIC |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | Strut |
| Suspension Rear | Trailing Arm |
| Steering Mechanism | - |
| Drive | rear |
| Fuel Combined (L/100km) | 9.2 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 75 |
| Fuel Type | Diesel |
| e10 Compatible | - |
| CO2 Combined | 244 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 225/55 R17 ? |
| Tyre Rear | 225/55 R17 ? |
| Front Rim Size | 6x17 |
| Rear Rim Size | 6x17 |
| Vehicle Height (mm) | 1900 |
|---|---|
| Vehicle Length (mm) | 5223 |
| Vehicle Width (mm) | 1901 |
| Ground Clearance (mm) | - |
| Wheelbase (mm) | 3430 |
| Turning Circle (m) | 12500 |
| Unladen Weight (kg) | 1920 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 2940 |
| Track Front (mm) | 1630 |
| Track Rear (mm) | 1630 |
| Towing Capacity Brake (kg) | 2000 |
| Towing Capacity Unbraked (kg) | 750 |
| Country Of Origin | Spain |
|---|---|
| Number of Doors | 5 |
| Seats | 3 |
| Service Interval KMs | 15000 |
| Service Interval Months | - |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | - |
| Warranty Months | 36 |
| Discontinued Date | 2009-12-31 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EU4 |
