Overview
The 2021 Hyundai i30 ACTIVE is a front 4d Sedan that was released to the Australian market on 294th October 2020 classified as a CN7.V1. The Hyundai i30 is regarded as a 4d sedan built in Korea with prices from a dealer as a used car starting at $24,790.
The Hyundai i30 is a front 4 door with 5 seats, powered by a 2.0L 4 engine that has 117 kW of power (at 6200 rpm) and 191 Nm of torque (at 4500 rpm) via a Six-speed Manual. Hyundai claims the i30 ACTIVE uses 7L/100km of unleaded in the combined city and highway cycle while putting out 160g of CO2. It has a 47L fuel tank, meaning it should be able to travel 671km per full tank.
The Hyundai i30 measures 1430mm (56.3 inches) in height, 4650mm (183.1 inches) in length, 1825mm (71.9 inches) in width with a 2720mm (107.1 inches) wheelbase that brings about a total of 1182kg (2605.9 lbs) of unladen weight. The i30 ACTIVE comes standard with 225/45 ZR 91W front tyres and 225/45 ZR 91W rear tyres. It requires a service every 12 months or 15000,000 km, whichever comes first. It has a 60 month, unlimited kmkm warranty.
The 2021 Hyundai i30 ACTIVE has a 140mm ground clearance with a 1200kg braked and 610kg unbraked towing capacity.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | MULTI-POINT INJECTION |
|---|---|
| Size (cc) | 1999 |
| Size (L) | 2.0L |
| Cylinders | 4 |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 117kW |
| Power RPM | 6200 |
| Torque | 191Nm |
| Torque RPM | 4500 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 6 SP MANUAL |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | strut |
| Suspension Rear | torsion beam |
| Steering Mechanism | POWER STEERING |
| Drive | front |
| Fuel Combined (L/100km) | 7 |
|---|---|
| Fuel Urban (L/100km) | 9.4 |
| Fuel Extra Urban (L/100km) | 5.7 |
| Tank Size (L) | 47 |
| Fuel Type | unleaded |
| e10 Compatible | - |
| CO2 Combined | 160 |
| CO2 Urban | 213 |
| CO2 Extra Urban | 129 |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 225/45 ZR 91W |
| Tyre Rear | 225/45 ZR 91W |
| Front Rim Size | 7x17 |
| Rear Rim Size | 7x17 |
| Vehicle Height (mm) | 1430 |
|---|---|
| Vehicle Length (mm) | 4650 |
| Vehicle Width (mm) | 1825 |
| Ground Clearance (mm) | 140 |
| Wheelbase (mm) | 2720 |
| Turning Circle (m) | 10800 |
| Unladen Weight (kg) | 1182 |
| Gross Combined Weight (kg) | 0 |
| Gross Vehicle Weight (kg) | 1740 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 1200 |
| Towing Capacity Unbraked (kg) | 610 |
| Compliance Plate Location | - |
|---|---|
| Country Of Origin | Korea |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 15000 |
| Service Interval Months | 12 |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | - |
| Warranty Months | 60 |
| Discontinued Date | 2021-05-31 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EU5 |
