Overview
The 2017 Hyundai i30 ACTIVE is a front 5d Hatchback that was released to the Australian market on 257th September 2016 classified as a GD4. The Hyundai i30 is regarded as a 5d hatchback built in Korea with prices from a dealer as a used car starting at $23,750.
The Hyundai i30 is a front 5 door with 5 seats, powered by a 1.8L 4 engine that has 107 kW of power (at 6500 rpm) and 175 Nm of torque (at 4700 rpm) via a Six-speed Automatic. Hyundai claims the i30 ACTIVE uses 7.3L/100km of unleaded in the combined city and highway cycle while putting out 170g of CO2. It has a 50L fuel tank, meaning it should be able to travel 685km per full tank.
The Hyundai i30 measures 1470mm (57.9 inches) in height, 4300mm (169.3 inches) in length, 1780mm (70.1 inches) in width with a 2650mm (104.3 inches) wheelbase that brings about a total of 1240kg (2733.7 lbs) of unladen weight. The i30 ACTIVE comes standard with 205/55 R 91H front tyres and 205/55 R 91H rear tyres. It requires a service every 12 months or 15000,000 km, whichever comes first. It has a 60 month, unlimited kmkm warranty.
The 2017 Hyundai i30 ACTIVE has a 140mm ground clearance with a 1300kg braked and 500kg unbraked towing capacity.
The Hyundai i30 has received a 5 star rating from ANCAP.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | MULTI-POINT INJECTION |
|---|---|
| Size (cc) | 1797 |
| Size (L) | 1.8L |
| Cylinders | 4 |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 107kW |
| Power RPM | 6500 |
| Torque | 175Nm |
| Torque RPM | 4700 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 6 SP AUTOMATIC |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | strut |
| Suspension Rear | torsion beam |
| Steering Mechanism | POWER STEERING |
| Drive | front |
| Fuel Combined (L/100km) | 7.3 |
|---|---|
| Fuel Urban (L/100km) | 10.3 |
| Fuel Extra Urban (L/100km) | 5.5 |
| Tank Size (L) | 50 |
| Fuel Type | unleaded |
| e10 Compatible | - |
| CO2 Combined | 170 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 205/55 R 91H |
| Tyre Rear | 205/55 R 91H |
| Front Rim Size | 6.5x16 |
| Rear Rim Size | 6.5x16 |
| Vehicle Height (mm) | 1470 |
|---|---|
| Vehicle Length (mm) | 4300 |
| Vehicle Width (mm) | 1780 |
| Ground Clearance (mm) | 140 |
| Wheelbase (mm) | 2650 |
| Turning Circle (m) | 10600 |
| Unladen Weight (kg) | 1240 |
| Gross Combined Weight (kg) | 0 |
| Gross Vehicle Weight (kg) | 1840 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 1300 |
| Towing Capacity Unbraked (kg) | 500 |
| Compliance Plate Location | - |
|---|---|
| Country Of Origin | Korea |
| Number of Doors | 5 |
| Seats | 5 |
| Service Interval KMs | 15000 |
| Service Interval Months | 12 |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | - |
| Warranty Months | 60 |
| Discontinued Date | 2017-11-28 |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | EU5 |
