    Ford Transit

    2010 Ford Transit Base Pricing and Spec

    From

    $41,490

    excl. on-roads

    Overview

    The 2010 Ford Transit Base is a rear-wheel drive, 4-door Panel Van that was released to the Australian market on 1st January 2010 classified as a VM. The Ford Transit is regarded as a Van over 3.5t built in Great Britain and when it was new had prices starting at $41,490.

    This Ford Transit is powered by a 2.4L 4-cylinder engine that has 103 kW of power (at 3500 rpm) and 375 Nm of torque (at 2000 rpm) via a Six-speed Manual transmission. Ford claims the Transit Base uses 10.4L/100km of Diesel in the combined city and highway cycle while putting out 274g of CO2. It has a 80L fuel tank, meaning it should be able to travel 769km per full tank

    The Ford Transit measures 2387mm (94.0 inches) in height, 5230mm (205.9 inches) in length, 1974mm (77.7 inches) in width with a 3300mm (129.9 inches) wheelbase that brings about a total of 1985kg (4376.2 lbs) of unladen weight. The Transit Base comes standard with 215/75 R16 113 front tyres and 215/75 R16 113 rear tyres. It has a 84 month, 200,000 km warranty.

    The Ford Transit has received a 3 star rating from ANCAP.

    Best For
    Work
    Transporting
    Warranty
    7Years
    or
    200,000km
    ANCAP Safety Rating
    Fuel Efficiency
    10.4L / 100km
    80 L769 km
    4D panel van
    Diesel
    2.4L
    rear
    6 MT
    2
    4

    Dimensions

    2387mm
    1974mm
    5230mm

    The dimensions shown above are for the base model.

    Specifications

    TypeTURBO DIESEL COMMON RAIL
    Size (cc)2402
    Size (L)2.4L
    Cylinders4
    CamshaftDual Overhead Cam
    Valves/Ports per Cylinder16
    Power103kW
    Power RPM3500
    Torque375Nm
    Torque RPM2000
    Bore Stroke-
    Compression Ratio-

    Transmission6 SP MANUAL
    Final Gear Ratio-
    Suspension FrontStrut
    Suspension RearBeam
    Steering Mechanism-
    Driverear

    Fuel Combined (L/100km)10.4
    Fuel Urban (L/100km)-
    Fuel Extra Urban (L/100km)-
    Tank Size (L)80
    Fuel TypeDiesel
    e10 Compatible-
    CO2 Combined274
    CO2 Urban-
    CO2 Extra Urban-

    Brake FrontDISC - VENTILATED
    Brake RearDISC
    Tyre Front215/75 R16 113
    Tyre Rear215/75 R16 113
    Front Rim Size5.5x16
    Rear Rim Size5.5x16

    Vehicle Height (mm)2387
    Vehicle Length (mm)5230
    Vehicle Width (mm)1974
    Ground Clearance (mm)-
    Wheelbase (mm)3300
    Turning Circle (m)11900
    Unladen Weight (kg)1985
    Gross Combined Weight (kg)6100
    Gross Vehicle Weight (kg)3300
    Track Front (mm)-
    Track Rear (mm)-
    Towing Capacity Brake (kg)2800
    Towing Capacity Unbraked (kg)750

    Country Of OriginGreat Britain
    Number of Doors4
    Seats2
    Service Interval KMs15000
    Service Interval Months-
    VIN Location-
    VIN Number-
    Warranty KMs200
    Warranty Months84
    Discontinued Date2011-12-11

    ANCAP Rating3
    Euro Air Pollution StandardEU4
