Overview
The 2009 Ford Mondeo XR is a front-wheel drive, 5-door Hatchback that was released to the Australian market on 4th October 2007 classified as a MA. The Ford Mondeo is regarded as a medium-sized car built in Belgium and when it was new had prices starting at $41,990.
This Ford Mondeo is powered by a 2.5L 5-cylinder engine that has 162 kW of power (at 5000 rpm) and 320 Nm of torque (at 1500 rpm) via a Six-speed Manual transmission. Ford claims the Mondeo XR uses 9.5L/100km of Premium Unleaded in the combined city and highway cycle while putting out 227g of CO2. It has a 70L fuel tank, meaning it should be able to travel 737km per full tank
The Ford Mondeo measures 1500mm (59.1 inches) in height, 4778mm (188.1 inches) in length, 1886mm (74.3 inches) in width with a 2850mm (112.2 inches) wheelbase that brings about a total of 1604kg (3536.2 lbs) of unladen weight. The Mondeo XR comes standard with 235/40 R18 ? front tyres and 235/40 R18 ? rear tyres. It has a 36 month, 100,000 km warranty.
The 2009 Ford Mondeo XR has a 103mm ground clearance with a 1600kg braked and 750kg unbraked towing capacity.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | TURBO MULTI-POINT INJECTION |
|---|---|
| Size (cc) | 2521 |
| Size (L) | 2.5L |
| Cylinders | 5 |
| Camshaft | Dual Overhead Cam |
| Valves/Ports per Cylinder | 20 |
| Power | 162kW |
| Power RPM | 5000 |
| Torque | 320Nm |
| Torque RPM | 1500 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 6 SP MANUAL |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | Strut |
| Suspension Rear | Multi-Link |
| Steering Mechanism | - |
| Drive | front |
| Fuel Combined (L/100km) | 9.5 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 70 |
| Fuel Type | Premium Unleaded |
| e10 Compatible | - |
| CO2 Combined | 227 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 235/40 R18 ? |
| Tyre Rear | 235/40 R18 ? |
| Front Rim Size | 8x18 |
| Rear Rim Size | 8x18 |
| Vehicle Height (mm) | 1500 |
|---|---|
| Vehicle Length (mm) | 4778 |
| Vehicle Width (mm) | 1886 |
| Ground Clearance (mm) | 103 |
| Wheelbase (mm) | 2850 |
| Turning Circle (m) | 11450 |
| Unladen Weight (kg) | 1604 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 2185 |
| Track Front (mm) | 1579 |
| Track Rear (mm) | 1595 |
| Towing Capacity Brake (kg) | 1600 |
| Towing Capacity Unbraked (kg) | 750 |
| Country Of Origin | Belgium |
|---|---|
| Number of Doors | 5 |
| Seats | 5 |
| Service Interval KMs | - |
| Service Interval Months | - |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 2009-01-04 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EU4 |
