Overview
The 2018 BMW 1 Series Urban Line is a rear-wheel drive, 5-door Hatchback that was released to the Australian market on 1st July 2017 classified as a F20. The BMW 1 Series is regarded as a Small Luxury built in Germany and when it was new had prices starting at $45,390.
This BMW 1 Series is powered by a 2.0L 4-cylinder engine that has 110 kW of power (at 4000 rpm) and 320 Nm of torque (at 1500 rpm) via an Eight-speed Automatic transmission. BMW claims the 1 Series Urban Line uses 4.2L/100km of Diesel in the combined city and highway cycle while putting out 110g of CO2. It has a 52L fuel tank, meaning it should be able to travel 1238km per full tank
The BMW 1 Series measures 1430mm (56.3 inches) in height, 4329mm (170.4 inches) in length, 1765mm (69.5 inches) in width with a 2690mm (105.9 inches) wheelbase that brings about a total of 1375kg (3031.4 lbs) of unladen weight. The 1 Series Urban Line comes standard with 225/40 ZR18 91W front tyres and 245/35 ZR18 91W rear tyres. It has a 36 month, unlimited km warranty.
The 2018 BMW 1 Series Urban Line has a 140mm ground clearance with a 1500kg braked and 690kg unbraked towing capacity.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | TURBO DIESEL COMMON RAIL |
|---|---|
| Size (cc) | 1995 |
| Size (L) | 2.0L |
| Cylinders | 4 |
| Camshaft | Dual Overhead Cam |
| Valves/Ports per Cylinder | 16 |
| Power | 110kW |
| Power RPM | 4000 |
| Torque | 320Nm |
| Torque RPM | 1500 |
| Bore Stroke | - |
| Compression Ratio | - |
| Transmission | 8 SP AUTOMATIC |
|---|---|
| Final Gear Ratio | - |
| Suspension Front | Strut |
| Suspension Rear | Multi-Link |
| Steering Mechanism | POWER STEERING |
| Drive | rear |
| Fuel Combined (L/100km) | 4.2 |
|---|---|
| Fuel Urban (L/100km) | 4.9 |
| Fuel Extra Urban (L/100km) | 3.8 |
| Tank Size (L) | 52 |
| Fuel Type | Diesel |
| e10 Compatible | - |
| CO2 Combined | 110 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 225/40 ZR18 91W |
| Tyre Rear | 245/35 ZR18 91W |
| Front Rim Size | 7.5x18 |
| Rear Rim Size | 8.5x18 |
| Vehicle Height (mm) | 1430 |
|---|---|
| Vehicle Length (mm) | 4329 |
| Vehicle Width (mm) | 1765 |
| Ground Clearance (mm) | 140 |
| Wheelbase (mm) | 2690 |
| Turning Circle (m) | - |
| Unladen Weight (kg) | 1375 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 1940 |
| Track Front (mm) | 1535 |
| Track Rear (mm) | 1569 |
| Towing Capacity Brake (kg) | 1500 |
| Towing Capacity Unbraked (kg) | 690 |
| Country Of Origin | Germany |
|---|---|
| Number of Doors | 5 |
| Seats | 5 |
| Service Interval KMs | - |
| Service Interval Months | - |
| VIN Location | - |
| VIN Number | - |
| Warranty KMs | - |
| Warranty Months | 36 |
| Discontinued Date | 2017-12-31 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EU6 |
